G1081368 Seat Compacto Comfort S Grammer PVC

Part number
G1081368
EAN
Unit
Each
Details

Air-sprung seat
Air-assisted weight adjustment

Application range
For small and narrow-track tractors, construction machines and mini excavators
Properties

Seat cushion width 400 mm
Spring travel: 80 mm
Height adjustment 60 mm, infinitely variable
Horizontal adjustment 210 mm
Weight 26 kg
Backrest inclination adjustment
Lumbar support, mechanically adjustable

Benefits

Offers optimised seat comfort in the smallest of spaces
A handle can be used to move the seat into the correct position

Long description

Application range:
For small and narrow-track tractors, construction machines and mini excavators
Benefits:
Offers optimised seat comfort in the smallest of spaces
A handle can be used to move the seat into the correct position
Consists of:
Seat
With compressor
Without backrest extension
Without arm rests
Details:
Air-sprung seat
Air-assisted weight adjustment
Properties:
Seat cushion width 400 mm
Spring travel: 80 mm
Height adjustment 60 mm, infinitely variable
Horizontal adjustment 210 mm
Weight 26 kg
Backrest inclination adjustment
Lumbar support, mechanically adjustable

Suspension type
Pneumatic
Upholstery material
PVC
Upholstery colour
Black
Total width
400 mm
Consists of

Seat
With compressor
Without backrest extension
Without arm rests

Armrests included
No
Backrest extension included
No
Seatbelt included
No
Contact switch included
No
Auto user weight adjustment
No
Model
MSG93/511
Height adjustment
6 cm
Depth
532 mm
Min. working load
50 kg
Suspension stroke
8 cm
Max. working load
130 kg
Suitable for machine/vehicle model
MSG 93 / 511
Total height
692 mm
Heating kit included
No
Total length
532 mm
Supply voltage
12 V
